CARATTERISTICHE HARDWARE
Interfaccia    3x Gigabit Ethernet Ports*6
Tasto    Reset
Alimentazione    12V DC / 24V Passive PoE (Passive PoE adapter included.)
Consumo energetico    11.5W
Dimensioni ( L x P x A )    3.1 x 2.4 x 8.8 in (79 × 60 × 224 mm)
Antenna    Internal 2×2 Dual-polarized directional MIMO antennas
5 GHz: 7.0 dBi
Horizontal:70°, Vertical: 70°
Weatherproof Enclosure    IP65
Tipo di montaggio    Pole Mounting (Accessories included)
CARATTERISTICHE WIRELESS
Coverage    1000m(3280ft)5
Standard wireless    IEEE 802.11 a/b/g/n/ac
Frequenza    5 GHz
Signal rate    5 GHz: Up to 867 Mbps
Funzionalità wireless    • Mesh*4
• MU-MIMO: 5G 2x2 MU-MIMO DL
• Load Balance
• Seamless Roaming(802.11r)
• Beamforming
• Airtime Fairness
• Multiple SSIDs:8
• Wireless Statistics
• Wireless Schedule
• Reboot Schedule
• RADIUS Accounting
• MAC Authentication
• Static IP/Dynamic IP
Sicurezza wireless    • VLAN
• Access Control
• Rogue AP Detection
• Captive Portal Authentication*4
• Maximum number of MAC Filter: 4,000
• WPA-Personal/Enterprise, WPA2-Personal/Enterprise
Potenza di trasmissione    • CE:
<23dBm (5 GHz, band 1/2, EIRP);
<30dBm (5 GHz band3, EIRP);

• FCC:
<22dBm (5 GHz band1/4)
GESTIONE
Omada App    Yes
Restore & Backup    Yes
Firmware update via Web    Yes
NTP    Yes
Centralized Management
• Omada Hardware Controller (OC300)
• Omada Hardware Controller (OC200)
• Omada Software Controller
• Omada Cloud-Based Controller
Cloud Access    Yes. Require the use of OC300, OC200, the Omada Software Controller, or Omada Cloud-Based Controller.
LED ON/OFF    Yes
Management MAC Access Control    Yes
SNMP    v1, v2c, v3
SSH    Yes
Gestione web-based    Yes
ALTRO
Certificazione    CE, FCC, RoHS
Contenuto della confezione
• EAP211-Bridge KIT
• Passive PoE Adapter
• Power Cord
• Installation Guide
• Mounting Kit
Ambiente
• Operating Temperature: -40 °C–70 °C (-40 °F–158 °F);
• Storage Temperature: -40 °C–70 °C (-40 °F–158 °F);
• Operating Humidity: 10%–90% non-condensing;
• Storage Humidity: 5%–90% non-condensing
